Tum lamp, left rear and right rear, Park/Tan lamp, left rear and right rearį7 10 Field Effect Transistor (FFT), Headlamp, leftį8 10 Field Effect Transistor (FET), Headlamp, rightį9 15 Field Effect Transistor (FET), Interior lamp, front and rear, Overhead lighting, Scuff plate lamp Left and Right frontį10 15 Exterior rear view mirror LH and RH side, Dimmer switch, Hazard flasher switch, Traction control/Ambient lighting switch, Message cater switch, Clockspring, Main light switch, Floor shifter, Ambient select switch, Luggage compartment lid release switch, Field Effect Transistors (FET)į12 7.5 Driver Seat Module (DSM), Seat adjust switch, driver side front, Driver Door Module (DDM), Exterior rear view minx switchį13 5 Accessory Protocol Interface Module (APIM)į14 10 Front Controls Interface Module (FCI M), Ambient lighting module. Keypad floor shifterį6 20 Field Effect Transistors (FET), Park/Turn lamp, left front and right front. EGR stepper motorĢ010 Ford Fusion Fuse Box Layout for Smart Junction Boxį5 10 SJB logic. Brake pedal position switch, Mass Air Flow/intake Air Temperature (MAFAAT) sensor. Powertrain Control Module (PCM)į47 10 AC clutch relay, Floor shifter, Heated PCV valve, Reverse lamp relayį48 15 Coil on plugs, Ignition transformer capacitor 1į49 +15 ++20 EVAP canister purge valve, Variable Camshaft Timing (VCT) solenoid 1 and 2, Powertrain Control Module (PCM), Heated Oxygen Sensor (HO2S) #11, 12, 21, 22.
rightį28 *60 Engine cooling fan motor / **80 Engine cooling fan motorį31 Seat control switch, passenger side frontį32 30 Seat control switch, driver side front Driver seat moduleį36 40 - Blower motor relay Fuel Pump diodeį37 - One Touch Integrated Start (OTIS) diodeį38 10 Exterior rear view mirror, LH and RHį45 15 Fuel injectors. Fl 50 Power Steering Control Module (PSCM)į2 50 40 Power Steering Control Module (PSCM)į12 30 Dual Climate Control Seat Module (DCSM)į23 10 Powertrain Control Module (PCM), EVAP canister vent control solenoidį26 High intensity discharge headlamp relay leftį27 High Intensity discharge headlamp relay.
